TECHNICAL FEATURES
  • Max. Capacity: 75 m3/h
  • Max. Height: 38 mSS
  • Pump Casing: PP / PVDF
  • Impermeability: Mechanic Seal, Ceramic Insert
  • Suction Connection: G 2½»
  • Push Connection: G 2″
  • Max. Viscosity: 500 cps
  • Motor Power: 11 kW, 2900 rpm, IP55,F, 2 pole, 230/400V, 50Hz, three phase
  • Max. Solid Particle: 11 mm
  • Pipe Lenght: 500 mm, 800 mm, 1000 mm / 1250 mm
