TECHNICAL FEATURES
  • Max. Flow Rate: 800 lt/min.
  • Max. Height: 80 mSS
  • Pump Casing: PP / PVDF / ALUM. / AISI 316
  • Diaphragm: Sant. + PTFE (Teflon)
  • Balls: PTFE / AISI 316
  • Seats: PP / PVDF / AISI 316
  • O-Ring: PTFE / Viton
  • Suction/Push Connection: G 3″
  • Max. Self-Priming Capacity: 4 m
  • Max. Air Supply Pressure: 8 Bar
  • Air Connection: G ¾”
  • Diameter: 10 mm
  • Max. Temperature: 95°C
  • Ex Proof Features: Zone 2
