The laser cutting machine uses two-dimensional drawings on the flat plate to cut sheet metal by moving the focused infrared light along programmed paths. The system carries the laser light to the focusing cutting head, which moves on the fixed sheet with the help of mirrors or fiber optic cable, depending on the technology of the laser machine. The cutting process takes place by melting the material in the region where the high power laser light focuses on very small diameters. Depending on the type of material, different gases are used to spray the molten material down the plate surface. These gases come out of the nozzle where the focused laser light comes out and controls the quality of the process.
Nitrogen Generators Specialized For Laser Cutting:
The most important consumable costs of fiber lasers, which have been used recently in laser cutting machines, is the Nitrogen (Nitrogen) gas used in cutting. Nitrogen gas is used for cutting stainless steel, alloy steel, aluminum and nickel alloys as they require higher pressure to remove slag from the cutting ranges. High gas pressure provides an extra mechanical force to remove molten material from the cutting range. Besides pressure, the purity of nitrogen gas is another important component of capturing the perfect cutting surface. Nitrogen gas purity directly affects material cutting quality.
In this process, Nitrogen gas supplied by customers stands out as an important expense for companies.
İdeal Makina has been the leader in the sector since 2005 as a solution partner of the superior German brand Inmatec with a total of more than 500 systems installed in the domestic and international market. Inmatec Nitrogen Generators has over 400 references in the Laser Cutting sector all over the world and İdeal Makina has over 70 references.
Through our nitrogen generators, you can produce nitrogen gas, which is supplied externally, at very affordable costs and you can increase your production intensity and profit by giving more competitive prices in the field.
We project these systems by considering parameters such as thickness of metal, type, cutting time and machine technology. Our systems that produce nitrogen gas up to 99.9999% purity offer excellent cutting quality.
Our systems also include high pressure (230 bar) bundle filling to meet your peak consumption and obtain the required gas stock.
IDEAL MAKINA PNC Series Nitrogen Generators produce the required nitrogen for laser machines in an economical manner at the desired purity, pressure and flow rate.
Nitrogen Gas In Laser Cutting;
All metals coming into contact with oxygen at high temperature are oxidized. This creates undesirable images such as blackening, rusting and burrs.
Nitrogen gas is used to prevent molten metal from oxidizing during the laser cutting process.
Bright, clean and burr-free appearance is obtained during cutting with nitrogen gas.
By applying nitrogen at high pressure on the laser beam path, smoothness of the laser beam is ensured.
The use of nitrogen at high pressure prevents particles that may form during cutting from bouncing back into the lens.
Nitrogen gas allows fast cooling of the cut piece.
By using nitrogen gas in the black (carbon steel) material cutting, a clean cutting surface suitable for direct painting is obtained.
Catox Nitrogen Generators Specialized For Laser Cutting:
IDEAL MAKINA is the one and only supplier in Turkey that can produce Nitrogen gas up to 99,9999% purity.
Instead of traditional liquid nitrogen supply for high thickness sheet cutting which requires high purity (1 ppm O2) and high amount of nitrogen gas, you can produce ultra pure nitrogen gas in your own place with our innovative and economical operation cost CATOX Ultra Pure Nitrogen Generators.
UHP Oxygen Generator Systems for Laser Cutting:
It is possible to produce 99.5% Purity Oxygen gas with Ideal Makina UHP Oxygen Generators.
IDEAL MAKINA offers Ultra High Purity Oxygen Generators with the ability to produce high purity Oxygen on site. UHP Oxygen Generators are the best alternative to the traditional gas supply method (O2 cylinders or liquid oxygen). Oxygen gas need is being supplied with our cost effective solutions and models in different capacities.
IdeaLAir Oilfree Dry Air Generators Specialized For Laser Cutting:
Ideal Air Oil Free Dry Air Generators designed by İdeal Makine with 18 barg compressed dry air produced according to ISO 8573.1 class 1.2.1 standards, is used directly as cutting air.
Our friendly staff is always ready for your help. You can call us for your orders or information requests.
