TECHNICAL FEATURES
  • Max. Flow Rate: 17 lt/min.
  • Max. Height: 80 mSS
  • Pump Casing: PP / PVDF / AISI 316 / ALUM.
  • Diaphragm: NBR + PTFE (Teflon)
  • Balls: PTFE (Teflon)
  • Seats: PP
  • O-Ring: EPDM
  • Suction/Push Connection: G ⅜”
  • Max. Self-Priming Capacity: +3 m
  • Max. Air Supply Pressure: 8 Bar
  • Air Connection: G ⅜”
  • Diameter: 0,5 mm
  • Max. Temperature: 95°C
  • Ex Proof Features: Zone 2
