TECHNICAL FEATURES
  • Max. Capacity: 30 m3/h
  • Max. Height: 20 mSS
  • Pump Casing: PP / PVDF
  • Impermeability: Seal
  • Suction Connection: G 2″
  • Push Connection: G 1½”
  • Weight: PP 22,5 kg, PVDF 23,5 kg
  • Max. Temperature: PP 60°C, PVDF 90°C
  • Max. Viscosity: 500 cps
  • Motor Power: 2,2 kW, 2900 rpm, IP55,F, 2 pole, 230/400V, 50Hz, three phase
